Socket manager for PGenericSocket. More...

#include <PGenericSocketManager.h>

Public Types
typedef _TBackend	Backend

typedef _TMockBackend	Mock

Public Member Functions
bool	addClientSocket (const _TSocketKey &name, const typename _TBackend::Param &param, const typename _TMockBackend::Param &mockParam)
	Create a client socket. More...

bool	addServerSocket (const _TSocketKey &name, const typename _TBackend::Param &param, const typename _TMockBackend::Param &mockParam)
	Create a server socket. More...

void	clear ()
	Clear the map of socket. More...

PSocketMode::PSocketMode	getMode () const
	Get if the current PGenericSocketManager is a mock. More...

PGenericSocket< _TBackend, _TMockBackend > *	getSocket (const _TSocketKey &name)
	Get a socket by name (or key) More...

bool	isConnected (const _TSocketKey &name) const
	Say if the given socket is connected. More...

bool	isSocketExist (const _TSocketKey &name) const
	Say if the socket exist with the given name. More...

	PGenericSocketManager (PSocketMode::PSocketMode mode=PSocketMode::NO_MOCK)
	Default constructor of PGenericSocketManager. More...

template<typename U >
bool	recvData (const _TSocketKey &name, U &data, PRecvFlag::PRecvFlag flag=PRecvFlag::BLOCK)
	Recieve data from the given socket. More...

bool	recvMsg (const _TSocketKey &name, typename _TBackend::Message &msg, PRecvFlag::PRecvFlag flag=PRecvFlag::BLOCK)
	Recieve message from the given socket. More...

void	removeSocket (const _TSocketKey &name)
	Remove the given socket. More...

template<typename U >
bool	sendData (const _TSocketKey &name, const U &data, PSendFlag::PSendFlag flag=PSendFlag::BLOCK)
	Send data on the given socket. More...

bool	sendMsg (const _TSocketKey &name, typename _TBackend::Message &msg, PSendFlag::PSendFlag flag=PSendFlag::BLOCK)
	Send message on the given socket. More...

void	setMode (PSocketMode::PSocketMode mode)
	Set if the current PGenericSocketManager is a mock. More...

virtual	~PGenericSocketManager ()
	Destructor of PGenericSocketManager. More...

Private Member Functions
void	initialisationPGenericSocketManager (PSocketMode::PSocketMode mode)
	Initialisation function of the class PGenericSocketManager. More...

Private Attributes
std::map< _TSocketKey, PGenericSocket< _TBackend, _TMockBackend > * >	p_mapSocket
	Map of the zmq sockets to be used by the manager. More...

PSocketMode::PSocketMode	p_mode
	Mode of the Socket (no mock, mock, mock_record) More...

Detailed Description

template<typename _TSocketKey, typename _TBackend, typename _TMockBackend>
class PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >

Socket manager for PGenericSocket.

Definition at line 17 of file PGenericSocketManager.h.

Member Typedef Documentation

◆ Backend

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

typedef _TBackend PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::Backend

Definition at line 19 of file PGenericSocketManager.h.

◆ Mock

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

typedef _TMockBackend PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::Mock

Definition at line 20 of file PGenericSocketManager.h.

Constructor & Destructor Documentation

◆ PGenericSocketManager()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::PGenericSocketManager ( PSocketMode::PSocketMode mode = PSocketMode::NO_MOCK )

Default constructor of PGenericSocketManager.

Parameters

mode	: Mode of the Socket (no mock, mock, mock_record)

Definition at line 16 of file PGenericSocketManager_impl.h.

                                                                                                               {
         initialisationPGenericSocketManager(mode);
 }

◆ ~PGenericSocketManager()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::~PGenericSocketManager

virtual

Destructor of PGenericSocketManager.

Definition at line 22 of file PGenericSocketManager_impl.h.

                                                                                     {
         clear();
 }

Member Function Documentation

◆ addClientSocket()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

bool PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::addClientSocket	(	const _TSocketKey &	name,
		const typename _TBackend::Param &	param,
		const typename _TMockBackend::Param &	mockParam
	)

Create a client socket.

Parameters

name	: name (key) to get the socket
param	: extra customisable parameters for the creation of the socket (depends on the backend)
mockParam	: parameters to initialise the mock

Returns: true if the socket has been created, false otherwise

Definition at line 49 of file PGenericSocketManager_impl.h.

 {
         PGenericSocket<_TBackend, _TMockBackend>* socket = new PGenericSocket<_TBackend, _TMockBackend>(p_mode);
         bool b(socket != NULL);
         if(b){
                 b &= socket->createClientSocket(param, mockParam);
                 if(b){
                         p_mapSocket[name] = socket;
                 }
         }
         return b;
 }

References PGenericSocket< _TBackend, _TMockBackend >::createClientSocket().

Referenced by threadRecievedData(), and threadRecievedMessage().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ addServerSocket()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

bool PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::addServerSocket	(	const _TSocketKey &	name,
		const typename _TBackend::Param &	param,
		const typename _TMockBackend::Param &	mockParam
	)

Create a server socket.

Parameters

name	: name (key) to get the socket
param	: extra customisable parameters for the creation of the socket (depends on the backend)
mockParam	: parameters to initialise the mock

Returns: true if the socket has been created, false otherwise

Definition at line 69 of file PGenericSocketManager_impl.h.

 {
         PGenericSocket<_TBackend, _TMockBackend>* socket = new PGenericSocket<_TBackend, _TMockBackend>(p_mode);
         bool b(socket != NULL);
         if(b){
                 b &= socket->createServerSocket(param, mockParam);
                 if(b){
                         p_mapSocket[name] = socket;
                 }
         }
         return b;
 }

References PGenericSocket< _TBackend, _TMockBackend >::createServerSocket().

Referenced by threadSendData(), and threadSendMessage().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ clear()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

void PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::clear

Clear the map of socket.

Definition at line 96 of file PGenericSocketManager_impl.h.

                                                                         {
         for(typename std::map<_TSocketKey, PGenericSocket<_TBackend, _TMockBackend>* >::iterator it(p_mapSocket.begin()); it != p_mapSocket.end(); ++it){
                 delete it->second;
         }
         p_mapSocket.clear();
 }

◆ getMode()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

PSocketMode::PSocketMode PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::getMode

Get if the current PGenericSocketManager is a mock.

Returns: Mode of the Socket (no mock, mock, mock_record)

Definition at line 38 of file PGenericSocketManager_impl.h.

                                                                                                   {
         return p_mode;
 }

◆ getSocket()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

PGenericSocket< _TBackend, _TMockBackend > * PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::getSocket ( const _TSocketKey & name )

Get a socket by name (or key)

Parameters

name	: of the socket to be used

Returns: pointer to the found socket, or NULL if the socket does not exist

Definition at line 140 of file PGenericSocketManager_impl.h.

 {
         typename std::map<_TSocketKey, PGenericSocket<_TBackend, _TMockBackend>* >::iterator it(p_mapSocket.find(name));
         if(it != p_mapSocket.end()){
                 return it->second;
         }else{
                 return NULL;
         }
 }

Referenced by PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::recvData(), and PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::sendData().

Here is the caller graph for this function:

◆ initialisationPGenericSocketManager()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

void PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::initialisationPGenericSocketManager ( PSocketMode::PSocketMode mode )

private

Initialisation function of the class PGenericSocketManager.

Parameters

mode	: Mode of the Socket (no mock, mock, mock_record)

Definition at line 178 of file PGenericSocketManager_impl.h.

                                                                                                                                  {
         p_mode = mode;
 }

◆ isConnected()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

bool PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::isConnected ( const _TSocketKey & name ) const

Say if the given socket is connected.

Parameters

name	: name of the socket to be checked

Returns: true if the socket exists and is connected, false otherwise

Definition at line 165 of file PGenericSocketManager_impl.h.

                                                                                                             {
         typename std::map<_TSocketKey, PGenericSocket<_TBackend, _TMockBackend>* >::const_iterator it(p_mapSocket.find(name));
         if(it != p_mapSocket.end()){
                 return it->second->isConnected();
         }
         return false;
 }

Referenced by threadSendData(), and threadSendMessage().

Here is the caller graph for this function:

◆ isSocketExist()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

bool PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::isSocketExist ( const _TSocketKey & name ) const

Say if the socket exist with the given name.

Parameters

name	: of the socket to be used

Returns: true if the socket exists, false otherwise

Definition at line 155 of file PGenericSocketManager_impl.h.

                                                                                                               {
         typename std::map<_TSocketKey, PGenericSocket<_TBackend, _TMockBackend>* >::const_iterator it(p_mapSocket.find(name));
         return it != p_mapSocket.end();
 }

◆ recvData()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

template<typename U >

bool PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::recvData	(	const _TSocketKey &	name,
		U &	data,
		PRecvFlag::PRecvFlag	flag = `PRecvFlag::BLOCK`
	)

inline

Recieve data from the given socket.

Parameters

name	: name of the socket to be used
data	: data to be recieved
flag	: flags to be used to send the message (BLOCK, NON_BLOCK, etc)

Returns: true on success, false otherwise

Definition at line 57 of file PGenericSocketManager.h.

                                                                                                            {
                         PGenericSocket<_TBackend, _TMockBackend> * socket = getSocket(name);
                         if(socket != NULL){
                                 return socket->recvData(data, flag);
                         }else{
                                 return false;
                         }
                 }

References PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::getSocket(), and PGenericSocket< _TBackend, _TMockBackend >::recvData().

Referenced by threadRecievedData().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ recvMsg()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

bool PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::recvMsg	(	const _TSocketKey &	name,
		typename _TBackend::Message &	msg,
		PRecvFlag::PRecvFlag	flag = `PRecvFlag::BLOCK`
	)

Recieve message from the given socket.

Parameters

name	: name of the socket to be used
msg	: message to be recieved
flag	: flags to be used to send the message (BLOCK, NON_BLOCK, etc)

Returns: true on success, false otherwise

Definition at line 126 of file PGenericSocketManager_impl.h.

                                                                                                                                                             {
         PGenericSocket<_TBackend, _TMockBackend> * socket = getSocket(name);
         if(socket != NULL){
                 return socket->recvMsg(msg, flag);
         }else{
                 return false;
         }
 }

References PGenericSocket< _TBackend, _TMockBackend >::recvMsg().

Referenced by threadRecievedMessage().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ removeSocket()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

void PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::removeSocket ( const _TSocketKey & name )

Remove the given socket.

Parameters

name	: name (key) of the socket to be removed

Definition at line 86 of file PGenericSocketManager_impl.h.

                                                                                                        {
         typename std::map<_TSocketKey, PGenericSocket<_TBackend, _TMockBackend>* >::iterator it(p_mapSocket.find(name));
         if(it != p_mapSocket.end()){
                 delete it->second;
                 p_mapSocket.erase(it);
         }
 }

◆ sendData()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

template<typename U >

bool PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::sendData	(	const _TSocketKey &	name,
		const U &	data,
		PSendFlag::PSendFlag	flag = `PSendFlag::BLOCK`
	)

inline

Send data on the given socket.

Parameters

name	: name of the socket to be used
data	: data to be sent
flag	: flag to be used to send the message (BLOCK, NON_BLOCK, etc)

Returns: true on success, false otherwise

Definition at line 39 of file PGenericSocketManager.h.

                                                                                                                  {
                         PGenericSocket<_TBackend, _TMockBackend> * socket = getSocket(name);
                         if(socket != NULL){
                                 return socket->sendData(data, flag);
                         }else{
                                 return false;
                         }
                 }

References PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::getSocket(), and PGenericSocket< _TBackend, _TMockBackend >::sendData().

Referenced by threadSendData().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ sendMsg()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

bool PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::sendMsg	(	const _TSocketKey &	name,
		typename _TBackend::Message &	msg,
		PSendFlag::PSendFlag	flag = `PSendFlag::BLOCK`
	)

Send message on the given socket.

Parameters

name	: name of the socket to be used
msg	: message to be sent
flag	: flags to be used to send the message (BLOCK, NON_BLOCK, etc)

Returns: true on success, false otherwise

Definition at line 110 of file PGenericSocketManager_impl.h.

                                                                                                                                                             {
         PGenericSocket<_TBackend, _TMockBackend> * socket = getSocket(name);
         if(socket != NULL){
                 return socket->sendMsg(msg, flag);
         }else{
                 return false;
         }
 }

References PGenericSocket< _TBackend, _TMockBackend >::sendMsg().

Referenced by threadSendMessage().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ setMode()

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

void PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::setMode ( PSocketMode::PSocketMode mode )

Set if the current PGenericSocketManager is a mock.

Parameters

mode	: Mode of the Socket (no mock, mock, mock_record)

Definition at line 30 of file PGenericSocketManager_impl.h.

                                                                                                      {
         p_mode = mode;
 }

Member Data Documentation

◆ p_mapSocket

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

std::map<_TSocketKey, PGenericSocket<_TBackend, _TMockBackend> *> PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::p_mapSocket

private

Map of the zmq sockets to be used by the manager.

Definition at line 79 of file PGenericSocketManager.h.

◆ p_mode

template<typename _TSocketKey , typename _TBackend , typename _TMockBackend >

PSocketMode::PSocketMode PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >::p_mode

private

Mode of the Socket (no mock, mock, mock_record)

Definition at line 76 of file PGenericSocketManager.h.

The documentation for this class was generated from the following files:

/builds/CTA-LAPP/PHOENIX_LIBS2/PhoenixZMQ/tmp_project/PhoenixSocket/src/PGenericSocketManager.h
/builds/CTA-LAPP/PHOENIX_LIBS2/PhoenixZMQ/tmp_project/PhoenixSocket/src/PGenericSocketManager_impl.h

Public Types

Public Member Functions

Private Member Functions

Private Attributes

Detailed Description

template<typename _TSocketKey, typename _TBackend, typename _TMockBackend> class PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >

Member Typedef Documentation

◆ Backend

◆ Mock

Constructor & Destructor Documentation

◆ PGenericSocketManager()

◆ ~PGenericSocketManager()

Member Function Documentation

◆ addClientSocket()

◆ addServerSocket()

◆ clear()

◆ getMode()

◆ getSocket()

◆ initialisationPGenericSocketManager()

◆ isConnected()

◆ isSocketExist()

◆ recvData()

◆ recvMsg()

◆ removeSocket()

◆ sendData()

◆ sendMsg()

◆ setMode()

Member Data Documentation

◆ p_mapSocket

◆ p_mode

template<typename _TSocketKey, typename _TBackend, typename _TMockBackend>
class PGenericSocketManager< _TSocketKey, _TBackend, _TMockBackend >
